Ifm | SKU:
IF-UA0040-E
Ifm UA0040 Evaluation System And Display For Analog Signals
$152.22 USD
Unit price
/
Unavailable
Shipping calculated at checkout.
Ifm UA0040 Evaluation System And Display For Analog Signals is backordered and will ship as soon as it is back in stock.
Industrial Automation Parts is only an authorized distributor for DeLock and is not authorized for any other manufacturers. Manufacturer's warranty and support do not apply. Our IAP warranty of three months is applicable.
Delivery And Shipping
Delivery And Shipping
Both Standard and Express shipping options are available at checkout.
Subscribe to our newsletter
Sign up for exclusive offers.
Ifm UA0040 Evaluation System And Display For Analog Signals
$152.22 USD
Unit price
/
Unavailable
Application
| Application | decentralized display, preprocessing and conversion of analog signals |
|---|
Electrical data
| Nominal voltage DC [V] | 24 |
|---|---|
| Current consumption [mA] | < 120 |
| Reverse polarity protection | yes |
Inputs / outputs
| Number of inputs and outputs | Number of analog inputs: 1 |
|---|
Inputs
| Number of analog inputs | 1 |
|---|---|
| Analog input (current) [mA] | 4...20 |
| Input resistance [Ω] | 500 |
| Resolution of analog input | 12 bit |
| Precision analog input [%] | 0,25 |
Interfaces
| Communication interface | IO-Link | ||||
|---|---|---|---|---|---|
| Supported DeviceIDs |
|
IO-Link Device
| Transmission type | COM3 (230,4 kBaud) |
|---|---|
| IO-Link revision | 1.1 |
| SIO mode | no |
| Required master port class | A/B |
| Min. process cycle time [ms] | 2 |
Operating conditions
| Ambient temperature [°C] | -25...60 |
|---|---|
| Storage temperature [°C] | -25...85 |
| Max. relative air humidity [%] | 95 |
| Max. height above sea level [m] | 3000 |
| Protection | IP 67; IP 65 |
Mechanical data
| Weight [g] | 51.709 |
|---|---|
| Material | Housing materials: plastics |
Displays / operating elements
| Display |
|
|---|
Remarks
| Pack quantity | 1 pcs. |
|---|
Electrical connection - Socket
| Connection | Connector: M12; coding: A |
|---|
Electrical connection - plug
| Connection | Connector: M12; coding: A |
|---|
