Ifm SD6101 Industrial Gas Counter
| Number of inputs and outputs | Number of digital outputs: 2; Number of analog outputs: 1 |
|---|---|
| Process connection | threaded connection 1/2" NPT DN15 |
| Measuring range |
|
|---|
| Measuring range |
|
|---|
| Measuring range |
|
|---|
| Application | for industrial applications |
|---|---|
| Media | Argon (Ar); carbon dioxide (CO2); nitrogen (N2) |
| Medium temperature [°F] | 32...140 |
| Pressure rating [bar] | 16 |
| Pressure rating [psi] | 232 |
| MAWP (for applications according to CRN) [bar] | 16 |
| Operating voltage [V] | 18...30 DC; (to SELV/PELV) |
|---|---|
| Current consumption [mA] | < 100 |
| Protection class | III |
| Reverse polarity protection | yes |
| Power-on delay time [s] | 1 |
| Number of inputs and outputs | Number of digital outputs: 2; Number of analog outputs: 1 |
|---|
| Total number of outputs | 2 |
|---|---|
| Output signal | switching signal; analog signal; pulse signal; IO-Link; (configurable) |
| Electrical design | PNP |
| Number of digital outputs | 2 |
| Output function | normally open / closed; (configurable) |
| Max. voltage drop switching output DC [V] | 2 |
| Permanent current rating of switching output DC [mA] | 250; (per output) |
| Number of analog outputs | 1 |
| Analog current output [mA] | 4...20; (scalable) |
| Max. load [Ω] | 500 |
| Pulse output | consumed quantity meter |
| Short-circuit protection | yes |
| Type of short-circuit protection | yes (non-latching) |
| Overload protection | yes |
| Low flow cut-off LFC |
|
|||
|---|---|---|---|---|
| Measuring dynamics | 1:300 |
| Pulse value | 0.040...4 000 000 scf |
|---|---|
| In steps of | 0.020...1000 scf |
| Pulse length [s] | 0,007...2 |
| Measuring range |
|
|||
|---|---|---|---|---|
| Display range |
|
|||
| Resolution |
|
|||
| Set point SP |
|
|||
| Reset point rP |
|
|||
| Analog start point ASP |
|
|||
| Analog end point AEP |
|
|||
| In steps of |
|
| Measuring range |
|
|||
|---|---|---|---|---|
| Display range |
|
|||
| Resolution |
|
|||
| Set point SP |
|
|||
| Reset point rP |
|
|||
