Ifm | SKU:
IF-AE3100-E
Ifm AE3100 Iiot Controller
$867.78 USD
Unit price
/
Unavailable
Shipping calculated at checkout.
Ifm AE3100 Iiot Controller is backordered and will ship as soon as it is back in stock.
🚚 We Ship Worldwide! Get your order delivered anywhere.
Delivery And Shipping
Delivery And Shipping
Both Standard and Express shipping options are available at checkout.
Subscribe to our newsletter
Sign up for exclusive offers.
Industrial Automation Parts is only an authorized distributor for DeLock and is not authorized for any other manufacturers. Manufacturer's warranty and support do not apply. Our IAP warranty of three months is applicable.
Ifm AE3100 Iiot Controller
$867.78 USD
Unit price
/
Unavailable
Product characteristics
| Communication interface | Ethernet; USB |
|---|
Application
| Application | freely programmable edgeDevice for industrial applications |
|---|
Electrical data
| Operating voltage [V] | 18...32 DC; (PELV) |
|---|---|
| Nominal voltage DC [V] | 24 |
| Power consumption [W] | 14; (max. power for USB devices: 1,5 A / 5 V) |
| Reverse polarity protection | yes |
Software / programming
| Parameter setting options | CODESYS 3.5 |
|---|---|
| PLC function to IEC 61131-3 | yes |
Interfaces
| Communication interface | Ethernet; USB |
|---|---|
| Number of Ethernet interfaces | 4 |
| Number of USB interfaces | 2 |
Ethernet
| Transmission standard | 10Base-T; 100Base-TX |
|---|---|
| Transmission rate | 10 MBit/s; 100 MBit/s |
| Type of connector | RJ45 |
| Protocol | EtherNet/IP; PROFINET; EtherCAT; Modbus TCP; OPC UA; IoT (MQTT, HTTP, Cloud connectors) |
USB
| Transmission rate | < 480 MBit/s | ||
|---|---|---|---|
| Type of connector | type A | ||
| Version | USB 2.0 | ||
| Note on interfaces |
|
Operating conditions
| Ambient temperature [°C] | -25...55 | ||
|---|---|---|---|
| Note on ambient temperature |
|
||
| Storage temperature [°C] | -25...85 | ||
| Max. relative air humidity [%] | 90; (non condensing) | ||
| Max. height above sea level [m] | 3000 | ||
| Protection | IP 20 | ||
| Degree of soiling | 2 |
Tests / approvals
| EMC |
|
|---|
Mechanical data
| Weight [g] | 685 |
|---|---|
| Type of mounting | DIN rail mounting |
| Material | housing: diecast aluminium passivated; stainless steel |
Displays / operating elements
| Display |
|
|---|
Hardware
| Processor | ARM 64 Bit Quad Core 1,2 GHz |
|---|---|
| Working memory | 1 GByte RAM |
| Mass storage | 8 GByte Flash |
| Removable storage | Micro SD card; SD; SDHX; SDXC; USB interface |
Data memory
| Real-time clock | yes; UTC, battery buffered |
|---|
Remarks
| Remarks |
|
|
|---|---|---|
| Pack quantity | 1 pcs. |
Electrical connection - Ethernet
| Connector: 4 x RJ45 |
Electrical connection - USB
| Connector: 2 x type A |
Electrical connection - voltage supply
| Connector: 1 x Cage clamp |
