Efector IFM EBC050 Splitter Box 4 Ports Connector M8

Name: Efector IFM EBC050 Splitter Box 4 Ports Connector M8
Availability: InStock

SKU WIR-1259-E

$85.00 USD - $85.00 USD

$85.00 USD

$85.00 USD - $85.00 USD

$85.00 USD

Availability:

Only 1 left!

Quantity

Delivery Option

Ups Express next day air or standard shipping is available at the checkout !

by Ifm

Industrial Automation Parts is only an authorized distributor for DeLock and is not authorized for any other manufacturers. Manufacturer's warranty and support do not apply. Our IAP warranty of three months is applicable.

Condition :

Description

Product Information

ZDO4F035MSS0000---STGH080MSS

Special Feature: Gold-Plated Contacts
Operating Voltage [V]: 10...30 DC; ("supply class 2" to cULus)
Protection Class: III
Max. Current Load Per Module/Slot [A]: 2
Max. Current Load Total [A]: 2
Outputs Electrical Design: PNP
Weight [g]: 88.5 (0,195 lb)
Dimensions [mm]: 23.7 X 30 X 85.4
Materials: PBT-GF 20; Brass Nickel-Plated
Molded-body Material: PBT-GF 20 / Brass, Nickel-Plated / PBT-GF 20 / Brass, Nickel-Plated
Number Of Ports Splitter Box: 4
Connector Type: M8
Connection: Connector: 1 x M12; Moulded Body: PBT-GF 20 / Brass, Nickel-Plated; Contacts: Gold-Plated
Displays / Operating Elements: Switching Status; 4 x LED, Yellow; Operation; 1 x LED, Green

Efector IFM EBC050 Splitter Box 4 Ports Connector M8
