F50-2.37 F50237 0108166
Piab
Suction Cup F50-2 With Support Ring
New And Sold By Unit
Features
- Suitable for flat objects.
- Good stability and little inherent movement.
- Recommended when the lifting force is parallel to the surface of the object.
- Cleats prevent thin, sensitive objects from being deformed and give extra friction when the lifting force is parallel.
Specification
- Application: HighLowTempCup, MarkFree, PlasticInjectionMoldedParts, DrySheetMetal, GlassHandling
- Suction cup shape: Flat
- Material: HNBR
- Suction cup model: F
- Weight: 0.49 oz
- Volume: 0.61 in³
- Name: F50-2
- Movement, vertical max.: 0.087 in
- Curve radius, min.: 2.17 in
Dimension
- Height: 0.69 in
- Outer diameter, actuated: 2.15 in
- Outer diameter: 2.087 in
