Ifm | SKU: SEN-2310-E | Barcode: DOES NOT APPLY

Efector Ifm IFS207 IFB3007-APKG/US-104 Inductive Sensor

Name: Efector Ifm IFS207 IFB3007-APKG/US-104 Inductive Sensor
Availability: InStock

$90.71 USD

Shipping calculated at checkout.

Industrial Automation Parts is only an authorized distributor for DeLock and is not authorized for any other manufacturers. Manufacturer's warranty and support do not apply. Our IAP warranty of three months is applicable.

Delivery And Shipping

Both Standard and Express shipping options are available at checkout.

Subscribe to our newsletter

Description

Electrical design
- PNP output
- Output function: normally closed
- Sensing range: 7mm
- Housing: threaded type, dimensions M12 x 1 / L = 50
Application
- Special feature: Gold-plated contacts; Increased sensing range
- Industrial applications / factory automation
Electrical data
- Operating voltage: 10-30 DCV
- Current consumption: < 10mA
- Protection class: II
- Reverse polarity protection: yes
Outputs
- Max. voltage drop switching output DC: 2.5V
- Permanent current rating of switching output DC: 100mA
- Switching frequency DC: 700Hz
- Short-circuit protection: yes
- Overload protection: yes
Detection zone
- Real sensing range Sr: 7 ± 10%
- Operating distance: 0-5.67mm
- Increased sensing range: yes
Accuracy / deviations
- Correction factor: steel: 1 / stainless steel: 0.7 / brass: 0.5 / aluminium: 0.4 / copper: 0.3
- Hysteresis: 3-15% of Sr
- Switch point drift: -10-10% of Sr
Operating conditions
- Ambient temperature: -25-70°C
Protection
- IP 67
