Ifm | SKU:
IF-O3X130-E
Ifm O3X130 3D Camera
$805.56 USD
Unit price
/
Unavailable
Shipping calculated at checkout.
Ifm O3X130 3D Camera is backordered and will ship as soon as it is back in stock.
Industrial Automation Parts is only an authorized distributor for DeLock and is not authorized for any other manufacturers. Manufacturer's warranty and support do not apply. Our IAP warranty of three months is applicable.
Delivery And Shipping
Delivery And Shipping
Both Standard and Express shipping options are available at checkout.
Subscribe to our newsletter
Sign up for exclusive offers.
Ifm O3X130 3D Camera
$805.56 USD
Unit price
/
Unavailable
Product characteristics
| Type of light | Infrared light |
|---|---|
| Image resolution 3D [px] | 224 x 172 |
| Angle of aperture 3D [°] | 58 x 44 |
| Max. reading rate [Hz] | 20 |
Application
| Application | output of 3D image data |
|---|
Electrical data
| Operating voltage tolerance [%] | -15...20 |
|---|---|
| Operating voltage [V] | 24 DC |
| Current consumption [mA] | < 170; (mean value at 24 VDC; peak current pulsed: <350) |
| Power consumption [W] | 4 |
| Protection class | III |
| Type of light | Infrared light |
| Wave length [nm] | 850 |
| Image sensor | PMD 3D ToF-Chip |
| Integrated lighting | yes; (infrared: 850 nm invisible radiation) |
Monitoring range
| Operating distance [mm] | 50...3000 | ||
|---|---|---|---|
| Note on operating distance |
|
||
| Image resolution 3D [px] | 224 x 172 | ||
| Angle of aperture 3D [°] | 58 x 44 | ||
| Max. reading rate [Hz] | 20 |
Measuring/setting range
| Measuring range [m] | < 30; (depending on settings, object size, and reflectivity) |
|---|
Software / programming
| Parameter setting options | via PC with ifm Vision Assistant or XML-RPC |
|---|
Interfaces
| Communication interface | Ethernet |
|---|---|
| Usage type | Parameter setting; Data transmission |
Ethernet
| Number of Ethernet interfaces | 1 | |||
|---|---|---|---|---|
| Transmission standard | 10Base-T; 100Base-TX | |||
| Transmission rate | 10; 100 | |||
| Protocol | TCP/IP | |||
| Factory settings |
|
Operating conditions
| Ambient temperature [°C] | -10...40 | ||
|---|---|---|---|
| Note on ambient temperature |
|
||
| Storage temperature [°C] | -40...85 | ||
| Protection | IP 50 | ||
| Max. immunity to extraneous light [klx] | 8 |
Tests / approvals
| EMC |
|
||||||||
|---|---|---|---|---|---|---|---|---|---|
| Shock resistance |
|
||||||||
| Vibration resistance |
|
||||||||
| Laser protection class | 1 | ||||||||
| Notes on laser protection |
|
||||||||
| Electrical safety |
|
Mechanical data
| Weight [g] | 240 |
|---|---|
| Dimensions [mm] | 80 x 43.5 x 21 |
| Material | housing: diecast zinc; front lens Illu: PMMA; front lens lens: float glass |
Remarks
| Pack quantity | 1 pcs. |
|---|
Electrical connection
| Cable: 1 m, PVC |
Electrical connection - Ethernet RJ45 connector
| RJ45_Steckverbinder | Connector: 1 x RJ45 |
|---|
Other data
Field of view size
| without lens distortion correction | |||
| Measuring range / distance [m] | Length [m] | Width [m] | |
| 0.50 | 0.50 | 0.40 | |
| 1.00 | 1.10 | 0.80 | |
| 1.50 | 1.60 | 1.20 | |
| 2.00 | 2.20 | 1.70 | |
| 2.50 | 2.70 | 2.10 | |
| 3.00 | 3.30 | 2.50 |
Repeatability
| Measuring range / distance [m] | Exposure time [µs] | Repeatability | Accuracy [mm] |
| Measured distance values (1 Sigma) on grey objects | |||
| reflectivity 18 % [mm] | |||
| 0.1...0.25 | 200 | ± 4 | ± 5 |
| 0.25...0.5 | 400 | ± 4 | ± 5 |
| 0.5...1 | 1000 | ± 6 | ± 10 |
| 1...2 | 2000 | ± 12 | ± 20 |
| 2...3 | 2000 | ± 50 | ± 40 |
| Repeatability | |
| based on | distance measurement of an individual pixel |
| Measured at | center of image with median filter |
| Ambient temperature | 20° C |
Temperature drift
| -10...+40° C [mm/K] |
| 0.2 |
Relative accuracy
| typical |
| ± 4 |
| measured at a reflectivity of 18% to 90% |
