Ifm | SKU:
IF-SDP110-E
Ifm SDP110 Gap Distance Sensor
$1,031.11 USD
Unit price
/
Unavailable
Shipping calculated at checkout.
Ifm SDP110 Gap Distance Sensor is backordered and will ship as soon as it is back in stock.
Industrial Automation Parts is only an authorized distributor for DeLock and is not authorized for any other manufacturers. Manufacturer's warranty and support do not apply. Our IAP warranty of three months is applicable.
Delivery And Shipping
Delivery And Shipping
Both Standard and Express shipping options are available at checkout.
Subscribe to our newsletter
Sign up for exclusive offers.
Ifm SDP110 Gap Distance Sensor
$1,031.11 USD
Unit price
/
Unavailable
Product characteristics
| Number of inputs and outputs | Number of digital outputs: 2; Number of analog outputs: 1 |
|---|---|
| Process connection | threaded connection G 1/4 DN8 |
Absolute
| Measuring range |
|
|---|
Relative (without unit of measurement)
| Measuring range |
|
|---|
Application
| Application | for industrial applications | ||
|---|---|---|---|
| Media | compressed air | ||
| Medium temperature [°C] | -10...60 | ||
| Min. bursting pressure |
|
||
| Pressure rating |
|
Electrical data
| Operating voltage [V] | 18...30 DC; (to SELV/PELV) |
|---|---|
| Current consumption [mA] | < 80 |
| Protection class | III |
| Reverse polarity protection | yes |
| Power-on delay time [s] | 1 |
Inputs / outputs
| Number of inputs and outputs | Number of digital outputs: 2; Number of analog outputs: 1 |
|---|
Inputs
| Inputs | teach input |
|---|
Outputs
| Output signal | switching signal; analog signal; IO-Link; (configurable) |
|---|---|
| Electrical design | PNP/NPN |
| Number of digital outputs | 2 |
| Output function | normally open / closed; (configurable) |
| Max. voltage drop switching output DC [V] | 2.5 |
| Permanent current rating of switching output DC [mA] | 150; (per output) |
| Number of analog outputs | 1 |
| Analog current output [mA] | 4...20; (scalable) |
| Max. load [Ω] | 500 |
| Short-circuit protection | yes |
| Type of short-circuit protection | yes (non-latching) |
| Overload protection | yes |
Measuring/setting range
Absolute
| Measuring range |
|
|
|---|---|---|
| Setting range |
|
|
| Resolution |
|
|
| Set point SP |
|
|
| Reset point rP |
|
|
| Analog start point ASP |
|
|
| Analog end point AEP |
|
|
| In steps of |
|
Relative (without unit of measurement)
| Measuring range |
|
||
|---|---|---|---|
| Setting range |
|
||
| Resolution |
|
||
| Set point SP |
|
||
| Reset point rP |
|
||
| Analog start point ASP |
|
||
| Analog end point AEP |
|
||
| In steps of |
|
Pressure monitoring
| Measuring range [bar] | -1...16 |
|---|---|
| Display range [bar] | -1...20 |
| Resolution [bar] | 0.05 |
| Set point SP [bar] | -0.92...16 |
| Reset point rP [bar] | -1...15.92 |
| Analog start point [bar] | -1...12.8 |
| Analog end point [bar] | 2.2...16 |
| In steps of [bar] | 0.01 |
Flow monitoring
| Measuring range |
|
|---|
